Wilo Smart Pump Yonos Maxo Z 30/0.5-7

This electronically controlled, Glandless circulator, synchronous motor with ECM technology and integrated power control for continuous differential pressure control.

Standard-equipped with:

• Preselectable control modes for optimum load adjustment: Δp-c (constant differential pressure), Δp-v (variable differential pressure)
• 3 speed stages (n = constant)
• LED for setting the setpoint and displaying error messages
• Electrical connection with the Wilo plug
• Compact design
• Signature Wilo green knob ensures an easy handling of the pump.

For flange-end pumps - flange versions:

• Standard version for DN 32 to DN 65 pumps: Combination flange PN 6/10 (flange PN 16 in accordance with EN 1092-2) for counter flanges PN 6 and PN 10
• Standard version for DN 80/DN 100 pumps: PN 6 flange (designed for PN 16 according to EN 1092-2) for PN 6 counter flange
