Wilo Smart Circulation Pump Stratos Pico Z 20/1-6

Electronically controlled STRATOS PICO-Z circulating pump for drinking water.

The pump is highly economical and conforms to new EU legislation. The pump is capable of operating both fully automatic and in manual mode.

Automatic mode (functions)

• Continuous power control depending on operating mode.
• Temperature regulation to maintain a constant return temperature in the drinking water circulation system.
• Thermal disinfection.
• Automatic unblocking function.

Manual mode (functions)

• Manual setting of operating mode, pump power, minimum temperature and flow.
• Reset function to reset the meter.
• Reset function to recall factory defaults.
• Key lock ("hold" function) to eliminate unwanted mode reset.

Mode display

• Current power consumption in W
• Total consumption of el. energy in kWh
• Display current flow in m3/h.
• Display the current temperature in °C.
• Error messages.

Features

• Power supply 230V / 50Hz.
• IP x4D protection
• The WILO connector ensures easy connection to the el. networks.
• Block-proof motor.
• Particle filter.
• Thermal insulation of pump components.

Scope of Delivery

• Pump.
• Heat insulation.
• Wilo connector.
• Seal.
• Installation and operating instructions.
